Manual double heads can filler

inquire now

Product Detiles

Equipment detailsSDMC-2 BEER CANNING  FILLER
1Size:W*L*H0.4×0.27×0.60M
2Weight15KG
3Packing Size (L*W*H)0.55×0.40×0.80M
4Gross Weight30KG
5Capacity1-2PCS/MIN/STATION|2 STATION
6PowerSingel Phase 110V-240VAC 50/60Hz is default
7Power consumption100W
8Main MaterialSUS304
9Beer SourceTemperature: 30.2 - 32F (-1 to 0C)
Carbonation:≤ 2.7 volumes CO2 (≤ 5.2 g/L CO2)
15-23PSI from plant system connected to canning system with 3/8“OD barbed fitting
10CO2 Regulator12-15 psi from plant system connected to canning system with 3/8“OD barbed fitting
11Time setting wayNo
12Connect type3/8“OD barbed fitting
13Can typeSDMC-2 can be configured for nearly all available can sizes!  Change over between different can dimensions is a snap, requiring only a few simple tools and less than 30 minutes.
14PackageComposite board boxes
15Lead time30-35days
