| Equipment details | PETAF-75 | ||||
| 1 | Size:W*L*H | 0.96X1.00X1.85M | |||
| 2 | Weight | 290KG | |||
| 3 | Packing Size （L*W*H) | 1.26X1.30X2.25M | |||
| 4 | Gross Weight | 400KG | |||
| 5 | Capacity | 20L-70pcs/h;30L-60pcs/h | |||
| 6 | Power | 3P AC380V 50Hz is default | |||
| 7 | Power port | 3P+N+G | |||
| 8 | Heater way | Steam Coiler 1KW | |||
| 9 | Main Material | SUS304 | |||
| 10 | Water tank material and volume | SUS304 Single tank / Volume=50L （1pcs） | |||
| 11 | Motor type and brand | SUS304 Pump Head | |||
| 12 | Temperature prode | NTC | |||
| 13 | Temperature control mode) | STC-200 | |||
| 14 | Time setting way | Siemens PLC 200 Smart | |||
| 15 | Connect type | 1.5" Tri-clamp | DIN male fitting | ||
| 16 | Spear type | A | S | D | ....... |
| 17 | Keg type | 230-322；532-600 | |||
| 18 | with flowmeter or not | Yes | No | ||
| 19 | Brand of flowmeter | Germany Burkert or IFM | |||
| 20 | Filling working procedure | Start-Lock down-Test the pressure by filling CO2-Steam spear sterilize-CO2 purge-Open spear-Fill the inside of the inner bag with CO2-Fill the outside of the inner bag with CO2 (exhaust the gas in the inner bag)-Filling (flow meter metering) isobaric filling-The difference of 0.2L reaches the set value(Drain valve open full exhaust)-The inner bag of the keg is full (the meter measures to the set value)-Close spear -Hot water clean spear-CO2 purge-Stop | |||
| 21 | Package | Composite board boxes | |||
| 22 | Lead time | 30-35 days | |||
